Serie | 8 60 cm Cooktop Induction

PXY675DC1E


The induction hob with PerfectFry: achieve perfect frying results thanks to automatic temperature control.

Highlights

PowerBoost: extra added power!

Extra added power: The improved PowerBoost function in our induction cooktops adds even more power to speed up the cooking process. For example, you can now boil 2 litres of water almost three times as fast as on a conventional glass-ceramic cooktop.

Reviews

Technical Specifications

Design
  • Stainless steel side profiles with bevelled ceramic front.
  • Can be combined with all hobs in comfort design
Comfort
  • 4 induction cooking zones
  • 17 - stage power setting for each cooking zone
  • Cooking zones: 1 x Ø 190 mm, 2.2 KW (max. Power levels 3.7 KW) Induction; 1 x Ø 380 mmx230 mm, 3.3 KW (max. Power levels 3.7 KW) Induction or 2 x Ø 190 mm, 2.2 KW (max. Power levels 3.7 KW) Induction
  • Electronic display
  • Time with time programming functions
    Alarm clock
    Count up timer per cooktop
Safety and Environment
  • Digital 2 stage residual heat indicator residual heat indicator for each cooking zone
  • Automatic pan recognition sensor
    PowerManagement Function
    Automatic Safety switch-off
    Control panel lock
    Wipe protection function
  • Spill protection
Cooktop type and Special Features
  • HighSpeed ceramic glass
  • Powerboost function for each cooking zone
  • PerfectFry sensor with 5 temperature settings
Power and size
  • 7.4 kW total connected load
  • Appliance: 606 x 527 mm
  • Min. worktop thickness: 30 mm
Technical Specifications
General
Energy input Electric
Type of control setting and signalling devices Direct Select 2.0, front
Safety device childproof lock, Key Lock, pan recognition, Power management function, Safety time-switch-off
Features 17 power levels, DirectSelect Premium, Extended FlexInduction, FlexInduction, FryingSensor Plus, Keep warm function, PerfectFry - frying sensor, PowerBoost
Design
Color of frame Alu, brushed
Color of surface Alu, brushed, Black
Construction type Built-in
Number of electric plates 0
Number of electric cooking zones 4
Type of frame Facette fro+rear,side profiles
Number of gas burners 0
Number of halogen plates 0
Installation typology Built-in
Total number of positions that can be used at the same time 4
Number of radiant plates 0
Number of electric warming zones 0
Size and weight
Dimensions of the product (mm) 51 x 606 x 527 mm
Net weight (kg) 16.0 kg
Cooking zone 2
Dimension of 2nd heating element (mm) 380 x 230 mm
Location of 2nd heating element center left
Power of 2nd heating element (kW) 3.3 kW
Type of 2nd heating element Induction heating
Cooking zone 3
Location of 3rd heating element back left
Cooking zone 4
Location of 4th heating element middle back
Cooking zone 5
Location of 5th heating element back right
Cooking zone 6
Dimension of 6th heating element (mm) 380 x 230 mm
Location of 6th heating element center right
Power of 6th heating element (kW) 3.3 kW
Type of 6th heating element Induction heating
Safety
Power on indicator
Residual heat indicator Separate
Safety device childproof lock, Key Lock, pan recognition, Power management function, Safety time-switch-off
Main on/off switch
Connection
Length electrical supply cord (cm) 110
Electrical connection rating (W) 7,400
Energy input Electric
Frequency (Hz) 50; 60 Hz

Download Manual

Here you can download the manual for your home appliance or view it on the screen.

Download Product Information

Technical details and information about all the comfort, efficiency, performance and security features, refer to the product characteristics.

Dimensional Drawings
